Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 229 8.730

229 8.730

Артикул: 9002290087300

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

8.73 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

MKG00102085

FamilyProducts

HSS SPIRALBOHRER 8,730 DIN 345RN MKSPANB

FHA Flute helix angle

23 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

67 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9002290087300

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

81 mm

LF Functional length

97.3 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

MKG Morse taper

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0010

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00102085

LPR Protruding length

100 mm

LS Shank length

65.5 mm

LU Usable length

66 mm

Name Identifying order number

229 8.730

NOF Flute count

OAL Overall length

162 mm

PL Point length

2.7 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN345

Working process

BVB - Drilling

WT Weight of item

0.069 kg
