Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 220 14.750

220 14.750

Артикул: 9002200147500

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

14.75 mm

DCONMSLD Shank diameter lower limit

-0.126 mm

DCONMSUD Shank diameter upper limit

-0.016 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL01470105

FamilyProducts

HSS SPIRALBOH, LANG 14,750 DIN 340LN ZYL

FHA Flute helix angle

30 Degree

FHH Flute helix hand

L - Hand of helix left

FHP Flute helix pitch

75 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

L - Left

ID Technical product number

9002200147500

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

144 mm

LF Functional length

215.5 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0147

LOC-03 DCONMS Diameter

14.75 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

f$11

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01470105

LPR Protruding length

149 mm

LS Shank length

76 mm

LU Usable length

125 mm

Name Identifying order number

220 14.750

NOF Flute count

OAL Overall length

220 mm

PL Point length

4.5 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN340

TCDCONMS ISO-tolerance class shank diameter

f11

Working process

BVB - Drilling

WT Weight of item

0.213 kg
