Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 217 22.620

217 22.620

Артикул: 9002170226200

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CRCLDIN Chip removal class

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

22.62 mm

DCONMSLD Shank diameter lower limit

-0.15 mm

DCONMSUD Shank diameter upper limit

-0.02 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL08900125

FamilyProducts

HSS SPIRALBOH, LANG 22,620 DIN 340RN ZYL

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

125 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9002170226200

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

180 mm

LF Functional length

268.2 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

0890

LOC-03 DCONMS Diameter

22.62 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

f$11

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL08900125

LPR Protruding length

185 mm

LS Shank length

95 mm

LU Usable length

152 mm

Name Identifying order number

217 22.620

NOF Flute count

OAL Overall length

275 mm

PL Point length

6.8 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN340

TCDCONMS ISO-tolerance class shank diameter

f11

Working process

BVB - Drilling

WT Weight of item

0.625 kg
