Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 1261 5.600

1261 5.600

Артикул: 9012610056000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

5.6 mm

DCONMSLD Shank diameter lower limit

-0.085 mm

DCONMSUD Shank diameter upper limit

-0.01 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00560105

FamilyProducts

HSCO SPIRALBOHRER 5,600 DIN 1897RN VA ZY

FHA Flute helix angle

40 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

21.2 mm

GRD2ND Standard designation of the grade 2nd application

HSCO

GRDMFG Grade manufacturers designation

HSCO

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

ID Technical product number

9012610056000

Interface codes

J6 / J61

ISO

ZYL00560105f$11

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

28 mm

LF Functional length

64.6 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0056

LOC-03 DCONMS Diameter

5.6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

f$11

LOC-03 ISO

ZYL00560105f$11

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00560105

LPR Protruding length

33 mm

LS Shank length

38 mm

LU Usable length

23 mm

Name Identifying order number

1261 5.600

NOF Flute count

OAL Overall length

66 mm

PL Point length

1.4 mm

SIG Point angle 1st step

130 Degree

STDNO Standard

DIN1897

TCDCONMS ISO-tolerance class shank diameter

f11

Working process

BVB - Drilling

WT Weight of item

0.01 kg
