Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 1243 7.000

1243 7.000

Артикул: 9012430070000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TIN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

7 mm

DCONMSLD Shank diameter lower limit

-0.009 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00700105

FamilyProducts

VHM S-RATIOBOH, RT100 U 7,000 WN RN 5XD

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

37.5 mm

GRD2ND Standard designation of the grade 2nd application

K/P

GRDMFG Grade manufacturers designation

K/P

GRDPRIO Standard designation of the grade main application

HC-K/P

HAND Cutting direction

R - Right

ID Technical product number

9012430070000

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

43 mm

LF Functional length

81.6 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0070

LOC-03 DCONMS Diameter

7 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00700105

LPR Protruding length

48 mm

LS Shank length

40 mm

LU Usable length

34 mm

Name Identifying order number

1243 7.000

NOF Flute count

OAL Overall length

83 mm

PL Point length

1.4 mm

SIG Point angle 1st step

140 Degree

STDNO Standard

WN 54

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.037 kg
