1131 10.200
1131 10.200
Артикул:
9011310102000
В наличии
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
3
CNSC Coolant entry style code
4 - With Coolant entry, axial on hole circle
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
4 - With Coolant exit, axial on hole circle
DC Cutting diameter minimum
10.2 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01205315
FamilyProducts
HSCO KUEHLKANALBOHR, 10,200 WN RN GT80 Z
FHA Flute helix angle
38 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
44.9 mm
GRD2ND Standard designation of the grade 2nd application
HSCO-KI
GRDMFG Grade manufacturers designation
HSCO-KI
GRDPRIO Standard designation of the grade main application
HSS-E
GRDSYC Grind style code
GG-GB
HAND Cutting direction
R - Right
ID Technical product number
9011310102000
Interface codes
J6 / J61
ISO
ZYL53G1200h$06
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
71 mm
LF Functional length
115.6 mm
LOC-03 CCFMS Connection code form
53
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03 ISO
ZYL53G1200h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01205315
LPR Protruding length
73 mm
LS Shank length
45 mm
LU Usable length
62 mm
Name Identifying order number
1131 10.200
NOF Flute count
2
OAL Overall length
118 mm
PL Point length
2.4 mm
SIG Point angle 1st step
130 Degree
STDNO Standard
WN
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
BVB - Drilling
WT Weight of item
0.068 kg
