Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 979 37.000

979 37.000

979 37.000 979 37.000

979 37.000

Gühring
Артикул: 9009790370000
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.052 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL02802105
DRVS Drive size
22 mm
FamilyProducts
HSS-E M,-GBO KURZ PG PG 29 DIN 40432
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
ID Technical product number
9009790370000
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0280
LOC-03 DCONMS Diameter
28 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02802105
LS Shank length
54.8 mm
Name Identifying order number
979 37.000
NOF Flute count
6
OAL Overall length
100 mm
PLCD Gate diameter
35.3 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN 40432
TCDCONMS ISO-tolerance class shank diameter
h9
TCL Tap chamfer length
3.174 mm
TDZ Thread diameter size
29
THFT Thread form type
PG
THL Thread cutting part length
25 mm
TP Thread pitch
1.587 mm
TPI Threads per inch
16 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.435 kg
