Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 5713 10.006

5713 10.006

5713 10.006 5713 10.006

5713 10.006

Gühring
Артикул: 5713 10.006
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
DAMPF ANGELASSEN
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
UN
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.036 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL00702105
DRVS Drive size
5.5 mm
FamilyProducts
HSSE VAP-GBO M10 X1,25 JIS UN40 POW-TAP
FHA Flute helix angle
40 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
37.4 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0070
LOC-03 DCONMS Diameter
7 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00702105
LS Shank length
35.3 mm
Name Identifying order number
5713 10.006
NOF Flute count
3
OAL Overall length
75 mm
PLCD Gate diameter
8.65 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
JIS B 4430
TCL Tap chamfer length
2.5 mm
TCTR Thread tolerance class
OH2
TD Thread diameter
10 mm
THFT Thread form type
MF
THL Thread cutting part length
14 mm
THOD Thread designation
MF10x1.25-OH2
TP Thread pitch
1.25 mm
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.024 kg
