Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 4628 10.006

4628 10.006

4628 10.006 4628 10.006

4628 10.006

Gühring
Артикул: 9046280100060
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
NANO-A
COMPC Company code
GG - Gühring
CRCLDIN Tool application class
N
CRCLMFG Chip removal class mfg
VA
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.036 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00702105
DRVS Drive size
5.5 mm
FamilyProducts
HSSE TIALN GBO VA45 DIN374 M10 X1,25 6GX
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
31.6 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
ID Technical product number
9046280100060
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0070
LOC-03 DCONMS Diameter
7 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00702105
LS Shank length
84.4 mm
Name Identifying order number
4628 10.006
NOF Flute count
3
OAL Overall length
100 mm
PLCD Gate diameter
8.65 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN374
TCDCONMS ISO-tolerance class shank diameter
h9
TCL Tap chamfer length
2.5 mm
TCTR Thread tolerance class
6GX
TD Thread diameter
10 mm
THFT Thread form type
MF
THL Thread cutting part length
14 mm
THOD Thread designation
MF10x1.25-6GX
TP Thread pitch
1.25 mm
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.034 kg
