Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 4464 16.662

4464 16.662

4464 16.662 4464 16.662

4464 16.662

Gühring
Артикул: 4464 16.662
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.043 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL01402105
DRVS Drive size
11 mm
FamilyProducts
HSS-E M-GBO PT 3/8 JIS VA-25 FORM C
FHA Flute helix angle
25 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
112.3 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0140
LOC-03 DCONMS Diameter
14 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01402105
LS Shank length
35.6 mm
Name Identifying order number
4464 16.662
NOF Flute count
4
OAL Overall length
65 mm
PLCD Gate diameter
14.15 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
JIS-WN1
TCL Tap chamfer length
2.674 mm
TCTR Thread tolerance class
JIS2
TDFR Thread diameter nominal fraction
3/8 in
TDIN Thread diameter nominal inch
0.375 in
THFT Thread form type
PT
THL Thread cutting part length
28 mm
TP Thread pitch
1.337 mm
TPI Threads per inch
19 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.067 kg
