Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 3977 28.575

3977 28.575

3977 28.575 3977 28.575 3977 28.575 3977 28.575

3977 28.575

Gühring
Артикул: 3977 28.575
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
TIN
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
UN
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.052 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL02272105
DRVS Drive size
17.07 mm
FamilyProducts
HSS-E S-GBO UN-40° FORM E 1 1/8 - 7 UNC
FHA Flute helix angle
40 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
107 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0227
LOC-03 DCONMS Diameter
22.758 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02272105
LS Shank length
70 mm
Name Identifying order number
3977 28.575
NOF Flute count
4
OAL Overall length
138.2 mm
PLCD Gate diameter
24.65 mm
PLG Plug style
E - Kappa r 23°
STDNO Standard
WN 376
TCL Tap chamfer length
5.444 mm
TCTR Thread tolerance class
2B
TDFR Thread diameter nominal fraction
1 1/8 in
TDIN Thread diameter nominal inch
1.125 in
THFT Thread form type
UNC
THL Thread cutting part length
37 mm
THOD Thread designation
UNC1 1/8-7-2B
TP Thread pitch
3.629 mm
TPI Threads per inch
7 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.503 kg
