Главная Каталог продукции Toolunited 12 301-01 - Thread cutting tap with offset shank 2846 5.486

2846 5.486

2846 5.486 2846 5.486 2846 5.486 2846 5.486

2846 5.486

Gühring
Артикул: 2846 5.486
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
DAMPF ANGELASSEN
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
ST
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.03 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/18/2024
DIN
ZYL00402105
DRVS Drive size
3 mm
FamilyProducts
HSS-E MA.-GBO UNF NR.12-28 DIN374 RN-40
FHA Flute helix angle
40 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
20.5 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00402105
LS Shank length
70.2 mm
Name Identifying order number
2846 5.486
NOF Flute count
3
OAL Overall length
80 mm
PLCD Gate diameter
4.5 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN 374~
TCL Tap chamfer length
1.814 mm
TCTR Thread tolerance class
2B
TDZ Thread diameter size
12
THFT Thread form type
UNF
THL Thread cutting part length
9 mm
THOD Thread designation
UNF12-28-2B
TP Thread pitch
0.907 mm
TPI Threads per inch
28 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.007 kg
