Главная Каталог продукции Toolunited 12 301-02 - Thread cutting tap with reinforced shank 4601UCS-M10-6H HG23

4601UCS-M10-6H HG23

4601UCS-M10-6H HG23 4601UCS-M10-6H HG23

4601UCS-M10-6H HG23

ZCC Cutting Tools
Артикул: 4601UCS-M10-6H HG23
В наличии
В корзину
Описание
Характеристики
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating / Покрытие
TiAlN
COMPC Company code
ZCC - ZCC Cutting Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
Delivery state
SF - Made to order
DIN
ZYL00702115
DN Neck diameter
6.5 mm
FamilyProducts
Tap, right-hand twist
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
HG23
HAND Cutting direction
R - Right
ID Identifying order number
4601UCS-M10-6H HG23
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
50 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0070
LOC-03 DCONMS Diameter
7 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00702115
NOF Flute count
3
OAL Overall length
100 mm
PLCD Gate diameter
8.3 mm
TCL Tap chamfer length
3 mm
TCTR Thread tolerance class
6H
TD Thread diameter
10 mm
THFT Thread form type
M
THL Thread cutting part length
15 mm
THOD Thread designation
M10x1.5-6H
TP Thread pitch
1.5 mm
Working process
No working processes available
