Главная Каталог продукции Toolunited 12 301-02 - Thread cutting tap with reinforced shank 1981 2.845

1981 2.845

1981 2.845 1981 2.845

1981 2.845

Gühring
Артикул: 9019810028450
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
OHNE
COMPC Company code
GG - Gühring
CRCLDIN Tool application class
N
CRCLMFG Chip removal class mfg
VA
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.03 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00352105
DRVS Drive size
2.7 mm
FamilyProducts
HSS-E MA-GBO NR, 4-40UNC DIN371RN FORM C
FHA Flute helix angle
40 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
10.8 mm
GRDMFG Grade manufacturers designation
HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
ID Technical product number
9019810028450
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
18 mm
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0035
LOC-03 DCONMS Diameter
3.5 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00352105
LS Shank length
33.1 mm
Name Identifying order number
1981 2.845
NOF Flute count
3
OAL Overall length
56 mm
PLCD Gate diameter
2.16 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN371~
TCDCONMS ISO-tolerance class shank diameter
h9
TCL Tap chamfer length
1.27 mm
TCTR Thread tolerance class
2 B
TDZ Thread diameter size
4
THFT Thread form type
UNC
THL Thread cutting part length
7 mm
THOD Thread designation
UNC4-40-2 B
TP Thread pitch
0.635 mm
TPI Threads per inch
40 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.001 kg
