Главная Каталог продукции Toolunited 12 301-02 - Thread cutting tap with reinforced shank 1152 10.000

1152 10.000

1152 10.000 1152 10.000

1152 10.000

Gühring
Артикул: 9011520100000
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating / Покрытие
TICN
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
UN
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCONMSLD Shank diameter lower limit
-0.036 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01002115
DRVS Drive size
8 mm
FamilyProducts
PM HSSE KI-C-MAGBO M10 DIN371 UN-50
FHA Flute helix angle
50 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
26.4 mm
GRD2ND Standard designation of the grade 2nd application
PM HSS-E
GRDMFG Grade manufacturers designation
PM HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E-PM
HAND Cutting direction
R - Right
ID Technical product number
9011520100000
Interface codes
J6 / J61
ISO
ZYL21G1000h$09
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
39 mm
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0100
LOC-03 DCONMS Diameter
10 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03 ISO
ZYL21G1000h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01002115
LS Shank length
54.3 mm
Name Identifying order number
1152 10.000
NOF Flute count
3
OAL Overall length
100 mm
PLCD Gate diameter
8.38 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN 371
TCDCONMS ISO-tolerance class shank diameter
h9
TCL Tap chamfer length
3 mm
TCTR Thread tolerance class
ISO2/6H
TD Thread diameter
10 mm
THFT Thread form type
M
THL Thread cutting part length
16 mm
THOD Thread designation
M10x1.5-ISO2/6H
TP Thread pitch
1.5 mm
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.048 kg
