Главная Каталог продукции Toolunited 12 301-02 - Thread cutting tap with reinforced shank 1068 3.505

1068 3.505

Артикул: 9010680035050

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

FIRE

COMPC Company code

GG - Gühring

CRCLDIN Tool application class

CRCLMFG Chip removal class mfg

CXSC Coolant exit style code

0 - Without coolant exit

DCONMSLD Shank diameter lower limit

-0.03 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00402105

DRVS Drive size

3 mm

FamilyProducts

PM HSSE FIRE GBO NR, 6 -40 UNJF DIN 371

FHA Flute helix angle

10 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

62.4 mm

GRD2ND Standard designation of the grade 2nd application

PM HSS-E

GRDMFG Grade manufacturers designation

PM HSS-E

GRDPRIO Standard designation of the grade main application

HSS-E-PM

HAND Cutting direction

R - Right

ID Technical product number

9010680035050

Interface codes

J6 / J61

ISO

ZYL21F4000h$09

ISYC Subclass

301-02 - Thread cutting tap with reinforced shank

LDRED Neck length

20 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0040

LOC-03 DCONMS Diameter

4 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03 ISO

ZYL21F4000h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00402105

LS Shank length

31.1 mm

Name Identifying order number

1068 3.505

NOF Flute count

OAL Overall length

56 mm

PLCD Gate diameter

2.85 mm

PLG Plug style

C - Kappa r 15°

STDNO Standard

DIN 371~

TCDCONMS ISO-tolerance class shank diameter

TCL Tap chamfer length

1.905 mm

TCTR Thread tolerance class

3BX

TDZ Thread diameter size

THFT Thread form type

UNJF

THL Thread cutting part length

12 mm

THOD Thread designation

UNJF6-40-3BX

TP Thread pitch

0.635 mm

TPI Threads per inch

40 1/in

TTPID Tap type identifier

1 - Machine tap

Working process

No working processes available

WT Weight of item

0.006 kg
