Главная Каталог продукции Toolunited 12 301-02 - Thread cutting tap with reinforced shank 1065 3.000

1065 3.000

Артикул: 9010650030000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

FIRE

COMPC Company code

GG - Gühring

CRCLDIN Tool application class

CRCLMFG Chip removal class mfg

CXSC Coolant exit style code

0 - Without coolant exit

DCONMSLD Shank diameter lower limit

-0.03 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00352105

DRVS Drive size

2.7 mm

FamilyProducts

PM HSSE FIRE GBO MJ 3 X0,5 DIN 371 NI-10

FHA Flute helix angle

10 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

53.5 mm

GRD2ND Standard designation of the grade 2nd application

PM HSS-E

GRDMFG Grade manufacturers designation

PM HSS-E

GRDPRIO Standard designation of the grade main application

HSS-E-PM

HAND Cutting direction

R - Right

ID Technical product number

9010650030000

Interface codes

J6 /

ISYC Subclass

301-02 - Thread cutting tap with reinforced shank

LDRED Neck length

18 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0035

LOC-03 DCONMS Diameter

3.5 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00352105

LS Shank length

33.8 mm

Name Identifying order number

1065 3.000

NOF Flute count

OAL Overall length

56 mm

PLG Plug style

C - Kappa r 15°

STDNO Standard

DIN 371

TCDCONMS ISO-tolerance class shank diameter

TCL Tap chamfer length

1.5 mm

TCTR Thread tolerance class

4HX

TD Thread diameter

3 mm

THFT Thread form type

THL Thread cutting part length

10 mm

THOD Thread designation

MJ3x0.5-4HX

TP Thread pitch

0.5 mm

TTPID Tap type identifier

1 - Machine tap

Working process

No working processes available

WT Weight of item

0.005 kg
