1064 4.166
1064 4.166
Артикул:
9010640041660
В наличии
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
TICN
COMPC Company code
GG - Gühring
CRCLDIN Chip removal class
H
CRCLMFG Chip removal class mfg
TI
CXSC Coolant exit style code
0 - Without coolant exit
DCONMSLD Shank diameter lower limit
-0.03 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00452105
DRVS Drive size
3.4 mm
FamilyProducts
PM HSSE C GBO NR,8 -36 UNJF DIN371 TI-15
FHA Flute helix angle
15 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
48.8 mm
GRD2ND Standard designation of the grade 2nd application
PM HSS-E
GRDMFG Grade manufacturers designation
PM HSS-E
GRDPRIO Standard designation of the grade main application
HSS-E-PM
HAND Cutting direction
R - Right
ID Technical product number
9010640041660
Interface codes
J6 /
ISYC Subclass
301-02 - Thread cutting tap with reinforced shank
LDRED Neck length
21 mm
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0045
LOC-03 DCONMS Diameter
4.5 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00452105
LS Shank length
37.4 mm
Name Identifying order number
1064 4.166
NOF Flute count
3
OAL Overall length
63 mm
PLCD Gate diameter
3.4 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN 371~
TCDCONMS ISO-tolerance class shank diameter
h9
TCL Tap chamfer length
2.118 mm
TCTR Thread tolerance class
3BX
TDZ Thread diameter size
8
THFT Thread form type
UNJF
THL Thread cutting part length
12 mm
THOD Thread designation
UNJF8-36-3BX
TP Thread pitch
0.706 mm
TPI Threads per inch
36 1/in
TTPID Tap type identifier
1 - Machine tap
Working process
No working processes available
WT Weight of item
0.008 kg
