Главная Каталог продукции Toolunited 12 309-08 - System tool for external threading T63H-KTNR-22

T63H-KTNR-22

T63H-KTNR-22

Kyocera

Артикул: THM04951

В наличии

В корзину

Описание

Характеристики

A1A SKJ Cutting edge angle major Pos. A

8

BLDA SKJ Tool style code Position A

8

CEATC Tool cutting edge angle type code

E - Front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCC Design configuration style code

A - Solid steel, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DHD Drop head design

0 - Normal

DIN

HSK06300795

DIN CSW1

KYO-22ER

END KAPP End chamfer

1

END KAPP ANGLE Kappungswinkel

65 Degree

END KAPP DIST End chamfer distance

-16.5 mm

FamilyProducts

HSK-T ICTM Standard

G3A SKJ Eingeschriebener Kreis Schneidkörper Pos.A

12.7 mm

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

-10 Degree

HAND Cutting direction

R - Right

HF Functional height

0 mm

ID Technical product number

THM04951

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-08 - System tool for external threading

KAPR Tool cutting edge angle

90 Degree

LF Functional length

67 mm

LH Head length

28.5 mm

LOC-03 CCFMS Connection code form

07

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

HSK Hollow taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0630

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK06300795

LPR Protruding length

67 mm

LTA Length tool assembly

67 mm

MIID Master insert identification

22ER300ISO

MTP Clamping type code

C - Top clamping without bore

Name Identifying order number

T63H-KTNR-22

OAL Overall length

99 mm

THSC Tool holder shape code

A - offset shank design

WF Functional width

45 mm

Working process

DGA - Thread turning, external

WT Weight of item

1.25 kg
