Главная Каталог продукции Toolunited 12 309-08 - System tool for external threading KPC3-KTNR22040-16

KPC3-KTNR22040-16

KPC3-KTNR22040-16

KPC3-KTNR22040-16

KPC3-KTNR22040-16

Kyocera

Артикул: THC14771

В наличии

В корзину

Описание

Характеристики

A1A SKJ Cutting edge angle major Pos. A

8

BLDA SKJ Tool style code Position A

8

CEATC Tool cutting edge angle type code

E - Front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCC Design configuration style code

A - Solid steel, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DHD Drop head design

0 - Normal

DIN

CCS03200195

DIN CSW1

KYO-16ER

END KAPP End chamfer

1

END KAPP ANGLE Kappungswinkel

65 Degree

END KAPP DIST End chamfer distance

-8 mm

FamilyProducts

Polygon Taper Shank KPC Series

G3A SKJ Eingeschriebener Kreis Schneidkörper Pos.A

9.525 mm

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

-10 Degree

HAND Cutting direction

R - Right

HF Functional height

0 mm

ID Technical product number

THC14771

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-08 - System tool for external threading

KAPR Tool cutting edge angle

90 Degree

LF Functional length

40 mm

LH Head length

18.5 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS03200195

LPR Protruding length

40 mm

LTA Length tool assembly

40 mm

MIID Master insert identification

16ER200ISO

MTP Clamping type code

C - Top clamping without bore

Name Identifying order number

KPC3-KTNR22040-16

OAL Overall length

59 mm

THSC Tool holder shape code

A - offset shank design

WF Functional width

22 mm

Working process

DGA - Thread turning, external

WT Weight of item

0.232 kg
