Главная Каталог продукции Toolunited 12 309-11 - System tool for OD grooving and parting KPC5-KGBAR35060-2225

KPC5-KGBAR35060-2225

KPC5-KGBAR35060-2225

KPC5-KGBAR35060-2225

KPC5-KGBAR35060-2225

Kyocera

Артикул: THC14763

В наличии

В корзину

Описание

Характеристики

A1A SKJ Cutting edge angle major Pos. A

1

A2A SKJ Stechbreite Nennmaß Schneidkörper Pos.A

2.5 mm

BLDA SKJ Tool style code Position A

1

C5A SKJ Eckenradius rechts Schneidkörper Pos.A

0.3 mm

C6A SKJ Eckenradius links Schneidkörper Pos.A

0.3 mm

CDX Cutting depth maximum

5.5 mm

CEATC Tool cutting edge angle type code

E - Front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CW Cutting width

2.5 mm

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCC Design configuration style code

A - Solid steel, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DHD Drop head design

0 - Normal

DIN

CCS05000195

DIN CSW1

KYO-GBA43R-S

END KAPP End chamfer

1

END KAPP ANGLE Kappungswinkel

55 Degree

END KAPP DIST End chamfer distance

-17.4 mm

FamilyProducts

Polygon Taper Shank KPC Series

G1A SKJ Schneidkörperlänge Schneidkörper Pos.A

4.76 mm

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

-6 Degree

HAND Cutting direction

R - Right

HF Functional height

0 mm

ID Technical product number

THC14763

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-11 - System tool for OD grooving and parting

KAPR Tool cutting edge angle

90 Degree

LF Functional length

60 mm

LH Head length

34 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000195

LPR Protruding length

60 mm

LTA Length tool assembly

60 mm

MIID Master insert identification

GBA43R250

MTP Clamping type code

P - Hole clamping, with straight bore

Name Identifying order number

KPC5-KGBAR35060-2225

OAL Overall length

90 mm

THSC Tool holder shape code

A - offset shank design

WF Functional width

33.75 mm

Working process

DEA - Outer diameter grooving

WT Weight of item

0.808 kg
