KPC4-KGDL27055-3T10

KPC4-KGDL27055-3T10

KPC4-KGDL27055-3T10

Kyocera
Артикул: THT05445
В наличии
В корзину
Описание
Характеристики
A1A SKJ Cutting edge angle major Pos. A
1
A2A SKJ Stechbreite Nennmaß Schneidkörper Pos.A
3 mm
BLDA SKJ Tool style code Position A
1
C5A SKJ Eckenradius rechts Schneidkörper Pos.A
0.4 mm
C6A SKJ Eckenradius links Schneidkörper Pos.A
0.4 mm
CDX Cutting depth maximum
10 mm
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CW Cutting width
3 mm
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCC Design configuration style code
A - Solid steel, with internal coolant supply
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DHD Drop head design
0 - Normal
DIN
CCS04000195
DIN CSW1
KYO-GD3020
END KAPP End chamfer
1
END KAPP ANGLE Kappungswinkel
60 Degree
END KAPP DIST End chamfer distance
-14 mm
FamilyProducts
Polygon Taper Shank KPC Series
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
L - Left
HF Functional height
0 mm
ID Technical product number
THT05445
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-11 - System tool for OD grooving and parting
KAPR Tool cutting edge angle
90 Degree
LF Functional length
55 mm
LH Head length
22 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS04000195
LPR Protruding length
55 mm
LTA Length tool assembly
55 mm
MIID Master insert identification
GDM3020N-040GM
MTP Clamping type code
C - Top clamping without bore
Name Identifying order number
KPC4-KGDL27055-3T10
OAL Overall length
79 mm
THSC Tool holder shape code
A - offset shank design
WF Functional width
27 mm
Working process
DEA - Outer diameter grooving
WT Weight of item
0.447 kg
