Главная Каталог продукции Toolunited 12 307-01 - Non-centre cutting single row end mill MFWN90050R-S32-05-5T

MFWN90050R-S32-05-5T

MFWN90050R-S32-05-5T

MFWN90050R-S32-05-5T

Kyocera
Артикул: THN08534
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
92 Degree
A2A Clearance angle major Pos. A
0 Degree
APMX Depth of cut maximum
5 mm
AZ Plunge depth maximum
0.8 mm
B3A Inscribed circle diameter Pos. A
8.8 mm
BD Body diameter
48.4 mm
BLDA Tool style code Position A
7
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
4.2 mm
CCONMS Connection count machine side
1
CICT Cutting item count
5
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
DC Cutting diameter
50 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL03200115
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
MFWN Mini Low cutting force 90°Milling cutter
GAMF Rake angle radial
-9 Degree
GAMP Rake angle axial
-9 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN08534
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LF Functional length
110 mm
LH Head length
30 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03200115
LPR Protruding length
30 mm
LS Shank length
80 mm
LU Usable length
25 mm
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFWN90050R-S32-05-5T
OAL Overall length
110 mm
RE Corner radius insert position A
0.8 mm
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
14 1/min
TCDCONMS ISO-tolerance class shank diameter
h7
Working process
FEC - Square shoulder milling,FNU - Groove milling
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
