Главная Каталог продукции Toolunited 12 307-01 - Non-centre cutting single row end mill MEV20-M10-06-2T

MEV20-M10-06-2T

MEV20-M10-06-2T

MEV20-M10-06-2T

Kyocera
Артикул: THN08496
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
0 Degree
APMX Depth of cut maximum
6 mm
AZ Plunge depth maximum
0.45 mm
B1A Cutting edge length Pos. A
12.384 mm
B3A Inscribed circle diameter Pos. A
7.15 mm
BD Body diameter
18.8 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
5.7 mm
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
DC Cutting diameter
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
SAD01000115
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
MEV High Performance Milling
GAMF Rake angle radial
17 Degree
GAMP Rake angle axial
17 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN08496
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LH Head length
30 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAD Screw mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0100
LOC-03 DCONMS Diameter
10.5 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAD01000115
LPR Protruding length
30 mm
LU Usable length
19 mm
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MEV20-M10-06-2T
OAL Overall length
48 mm
RMPX Ramping angle maximum
1 Degree
RPMX Rotational speed maximum
32000 1/min
THSZMS Connection thread nominal size machine side
M10
Working process
FEC - Square shoulder milling,FNU - Groove milling,FZI - Circular milling
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
