Главная Каталог продукции Toolunited 12 307-01 - Non-centre cutting single row end mill 1DJ1R025035X7R00

1DJ1R025035X7R00

1DJ1R025035X7R00 1DJ1R025035X7R00 1DJ1R025035X7R00

1DJ1R025035X7R00

Ingersoll
Артикул: 6247297
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
7 mm
CCONMS Connection count machine side
2
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
10/15/2023
DIN
SAD01200115
DN Neck diameter
22 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
End Mill 1DJ1R...X
HAND Cutting direction
R - Right
ID Technical product number
6247297
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAD Screw mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0120
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAD01200115
LPR Protruding length
35 mm
Name Identifying order number
1DJ1R025035X7R00
OAL Overall length
57 mm
Working process
FEC - Square shoulder milling,FNU - Groove milling,FPL - Face milling
WT Weight of item
0.11 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
