Главная Каталог продукции Toolunited 12 301-00 - Thread cutting tap, forming tap, cutting die unspecified 4127 21.900

4127 21.900

Артикул: 9041270219000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

TIN

COMPC Company code

GG - Gühring

CRCLDIN Tool application class

CRCLMFG Chip removal class mfg

CXSC Coolant exit style code

0 - Without coolant exit

DCONMSLD Shank diameter lower limit

-0.043 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL01802105

DRVS Drive size

14.5 mm

FamilyProducts

HSS-E S-MASCH-GBO 1/2 NPTF RN-25 VA

FHA Flute helix angle

25 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

137.8 mm

GRDMFG Grade manufacturers designation

HSS-E

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

ID Technical product number

9041270219000

Interface codes

J6 / J61

ISO

ZYL21G1800h$09

ISYC Subclass

301-00 - Thread cutting tap, forming tap, cutting die unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0180

LOC-03 DCONMS Diameter

18 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03 ISO

ZYL21G1800h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01802105

LS Shank length

80.9 mm

Name Identifying order number

4127 21.900

NOF Flute count

OAL Overall length

125 mm

PLCD Gate diameter

17.8 mm

PLG Plug style

C - Kappa r 15°

STDNO Standard

WN 31

TCDCONMS ISO-tolerance class shank diameter

TCL Tap chamfer length

3.628 mm

TDFR Thread diameter nominal fraction

1/2 in

TDIN Thread diameter nominal inch

0.5 in

TG Taper ratio

1:16

THFT Thread form type

NPTF

THL Thread cutting part length

27 mm

TP Thread pitch

1.814 mm

TPI Threads per inch

14 1/in

TTPID Tap type identifier

1 - Machine tap

Working process

No working processes available

WT Weight of item

0.246 kg
