WNMG 080408-NR IC5010
WNMG 080408-NR IC5010
Артикул:
5550537
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
1 - With chip breaker one-side
CBMD Chip breaker manufacturers designation
NR
CECC Cutting edge condition code
E - Rounded
COATN Coating
TiCN+Al2O3+TiN
COMPC Company code
IS - Iscar
Delivery state valid from
4/1/2022
DIN
WN0804082N
EPSR Insert included angle
80 Degree
FamilyProducts
Double-Sided Trigon Inserts with a Special Chipformer for Heavy Machining
GRDMFG Grade manufacturers designation
IC5010
IC Inscribed circle diameter
12.7 mm
ID Technical product number
5550537
IFS Insert mounting style code
2 - With cylindrical bore
IH Insert hand
N - Neutral
Interface codes
J6 / J441
ISISO ISO property
1
ISO
ISO$WN0804082NB$$08
ISYC Subclass
201-07 - Trigon insert
L Cutting edge length
8.7 mm
LOC-03 ISO
ISO$WN0804082NB$$08
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
WN0804082N
Name Identifying order number
WNMG 080408-NR IC5010
RE Corner radius
0.8 mm
S Insert thickness
4.76 mm
Working process
No working processes available
WT Weight of item
0.01 kg
