WNHU060408PNR-GM YBS303

Артикул: WNHU060408PNR-GM YBS303

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

nc-TiAlN

COMPC Company code

ZCC - ZCC Cutting Tools

D1 Fixing hole diameter

3.5 mm

Delivery state valid from

8/1/2024

DIN

ZCC-WNHU0604

EPSR Insert included angle

88 Degree

FamilyProducts

WN** negative insert

GRDMFG Grade manufacturers designation

YBS303

GRDPRIO Standard designation of the grade main application

HC S 30

IC Inscribed circle diameter

9.525 mm

ID Identifying order number

WNHU060408PNR-GM YBS303

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

ZCC-WNHU0604

RE Corner radius

0.8 mm

S Insert thickness

4.704 mm

S1 Insert thickness total

4 mm

TCINS Tolerance class insert

Working process

No working processes available
