Главная Каталог продукции Toolunited 12 201-07 - Trigon insert WBMT 060102L IC520N

WBMT 060102L IC520N

Артикул: 6166989

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

5 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating

TiCN+TiN

COMPC Company code

IS - Iscar

Delivery state valid from

4/1/2022

DIN

WB0601023L

EPSR Insert included angle

80 Degree

FamilyProducts

Trigon Inserts with a 5° Positive Flank Ground Chipformer for Finish Turning

GRDMFG Grade manufacturers designation

IC520N

IC Inscribed circle diameter

3.97 mm

ID Technical product number

6166989

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

L - Left

Interface codes

J6 / J441

ISISO ISO property

ISO

ISO$WB0601023LB$$02

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

2.18 mm

LOC-03 ISO

ISO$WB0601023LB$$02

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

WB0601023L

Name Identifying order number

WBMT 060102L IC520N

RE Corner radius

0.2 mm

S Insert thickness

1.59 mm

Working process

No working processes available
