Главная Каталог продукции Toolunited 12 201-02 - Square insert SNMM 250924-R3P IC830

SNMM 250924-R3P IC830

Артикул: 3328887

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

R3P

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

AlTiN+TiN

COMPC Company code

IS - Iscar

D1 Fixing hole diameter

9.12 mm

Delivery state valid from

4/1/2022

DIN

SN2509242N

EPSR Insert included angle

90 Degree

FamilyProducts

Single-Sided Square Inserts for Rough Turning Applications on Steel

GRDMFG Grade manufacturers designation

IC830

IC Inscribed circle diameter

25.4 mm

ID Technical product number

3328887

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

ISO$SN2509242NB$$24

ISYC Subclass

201-02 - Square insert

L Cutting edge length

25.4 mm

LOC-03 ISO

ISO$SN2509242NB$$24

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN2509242N

Name Identifying order number

SNMM 250924-R3P IC830

RE Corner radius

2.4 mm

S Insert thickness

9.52 mm

Working process

No working processes available
