Главная Каталог продукции Toolunited 12 201-02 - Square insert QNMG 090404-TF IC830

QNMG 090404-TF IC830

Артикул: 3308176

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

AlTiN+TiN

COMPC Company code

IS - Iscar

Delivery state valid from

4/1/2022

DIN

QN0904042N

EPSR Insert included angle

80 Degree

FamilyProducts

Double-Sided Inserts with Four 80° Corners for General Applications

GRDMFG Grade manufacturers designation

IC830

IC Inscribed circle diameter

9.52 mm

ID Technical product number

3308176

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

ISO$QN0904042NB$$04

ISYC Subclass

201-02 - Square insert

L Cutting edge length

10.32 mm

LOC-03 ISO

ISO$QN0904042NB$$04

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

QN0904042N

Name Identifying order number

QNMG 090404-TF IC830

RE Corner radius

0.4 mm

S Insert thickness

4.76 mm

Working process

No working processes available

WT Weight of item

0.01 kg
