Главная Каталог продукции Toolunited 12 201-10 - Round insert ROHX1204M08-A57 WKK25S

ROHX1204M08-A57 WKK25S

Артикул: 7985267

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CBMD Chip breaker manufacturers designation

A57

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

TiAlN+Al2O3+(Al)

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

12/1/2023

DIN

W-RO1204M03NB$8M0

FamilyProducts

Positive round ROHX

GRDMFG Grade manufacturers designation

WKK25S

IC Inscribed circle diameter

12 mm

ID Technical product number

7985267

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

WR$$RO1204M03NB$8M0

ISYC Subclass

201-10 - Round insert

LOC-03 ISO

WR$$RO1204M03NB$8M0

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

W-RO1204M03NB$8M0

M M-dimension

12 mm

Name Identifying order number

ROHX1204M08-A57 WKK25S

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

ROHX1204M08

STDDESAnsi Standard designation ANSI

ROHX43V8

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

FPL - Face milling

WT Weight of item

0.005 kg
