TGTL 1212-2T15SH-L120-IQ

Артикул: 2302341

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

COMPC Company code

IS - Iscar

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/1/2022

DIN CSW1

IS-432698562594980

FamilyProducts

Integral Shank Short-Head TANG-GRIP Toolholders for Parting and Grooving

HAND Cutting direction

L - Left

HF Functional height

12.1 mm

ID Technical product number

2302341

Interface codes

Interface codes CSW1

J41 / J441

ISO CSW1

IS$$432698562594980

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

LOC-03 B Shank width

12 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CZCMS Connection size code

1212

LOC-03 H Shank height

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

Name Identifying order number

TGTL 1212-2T15SH-L120-IQ

OAL Overall length

120 mm

Working process

No working processes available

WT Weight of item

0.12 kg
