Главная Каталог продукции Toolunited 12 309-01 - Tool holder for longitudinal and transversal turning SCLCL1616H09

SCLCL1616H09

SCLCL1616H09

Sumitomo

Артикул: 5338

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

7 Degree

B3A Inscribed circle diameter Pos. A

9.525 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

3.97 mm

CEATC Tool cutting edge angle type code

B - Side and front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.4 mm

DCC Design configuration style code

S - Solid steel, no construction features

DCP Data chip provision

0 - Without data chip

DHD Drop head design

0 - Normal

DIN

VKT16160105

DIN CSW1

CC09T3043N

END KAPP End chamfer

1

EPSR Insert included angle

80 Degree

FamilyProducts

SCLCL1616H09

GAMF Rake angle radial

0 Degree

GAMO Rake angle orthogonal

0 Degree

GAMP Rake angle axial

0 Degree

HAND Cutting direction

L - Left

HF Functional height

16 mm

ID Technical product number

5338

Interface codes

J6 /

Interface codes CSW1

J41 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

95 Degree

L Cutting edge length

9.7 mm

LAMS Inclination angle

0 Degree

LF Functional length

100 mm

LH Head length

18 mm

LOC-03 B Shank width

16 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

1616

LOC-03 H Shank height

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT16160105

MIID Master insert identification

CCGT09T304

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

SCLCL1616H09

OAL Overall length

100 mm

STDDES Standard designation

SCLCL1616H09

SX Shank cross section shape code

01 - Square shank

THSC Tool holder shape code

A - offset shank design

WF Functional width

20 mm

Working process

DDA - External turning
