Главная Каталог продукции Toolunited 12 309-14 - System tool, neutral design for OD turning PSC50SVVCN0006016

PSC50SVVCN0006016

PSC50SVVCN0006016

PSC50SVVCN0006016

PSC50SVVCN0006016

Sumitomo

Артикул: 220974

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

7 Degree

B3A Inscribed circle diameter Pos. A

9.525 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

4.76 mm

CEATC Tool cutting edge angle type code

S - Side lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.8 mm

DCC Design configuration style code

S - Solid steel, no construction features

DCP Data chip provision

0 - Without data chip

Delivery state

KA - Unknown

DIN

CCS05000195

DIN CSW1

VC1604083N

EPSR Insert included angle

35 Degree

GAMO Rake angle orthogonal

0 Degree

HAND Cutting direction

N - Neutral

ID Technical product number

220974

Interface codes

J6 /

Interface codes CSW1

J41 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISYC Subclass

309-14 - System tool, neutral design for OD turning

KAPR Tool cutting edge angle

72.5 Degree

LAMS Inclination angle

0 Degree

LF Functional length

60 mm

LH Head length

33.5 mm

LOC-03 CCFMS Form

01

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000195

LPR Protruding length

60 mm

LTA Length tool assembly

60 mm

MIID Master insert identification

VCMT160408

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

PSC50SVVCN0006016

THSC Tool holder shape code

G - straight shank design

WF Functional width

0 mm

Working process

DDA - External turning
