Главная Каталог продукции Toolunited 12 309-07 - System tool for external turning KPC5-DWLNL35060-08S

KPC5-DWLNL35060-08S

KPC5-DWLNL35060-08S

KPC5-DWLNL35060-08S

KPC5-DWLNL35060-08S

Kyocera

Артикул: THC14737

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

0 Degree

B3A Inscribed circle diameter Pos. A

12.7 mm

BLDA Tool style code Position A

7

C1A Insert thickness Pos. A

4.76 mm

CEATC Tool cutting edge angle type code

B - Side and front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.8 mm

DCC Design configuration style code

S - Solid steel, no construction features

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DHD Drop head design

0 - Normal

DIN

CCS05000195

DIN CSW1

WN0804082N

END KAPP End chamfer

0

EPSR Insert included angle

80 Degree

FamilyProducts

Polygon Taper Shank KPC Series

GAMF Rake angle radial

-6 Degree

GAMP Rake angle axial

-6 Degree

HAND Cutting direction

L - Left

HF Functional height

0 mm

ID Technical product number

THC14737

Interface codes

J6 /

Interface codes CSW1

J41 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISYC Subclass

309-07 - System tool for external turning

KAPR Tool cutting edge angle

95 Degree

L Cutting edge length

8.687 mm

LF Functional length

60 mm

LH Head length

37 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000195

LPR Protruding length

60 mm

LTA Length tool assembly

60 mm

MIID Master insert identification

WNMG080408

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

KPC5-DWLNL35060-08S

OAL Overall length

90 mm

THSC Tool holder shape code

A - offset shank design

WF Functional width

35 mm

Working process

DDA - External turning

WT Weight of item

0.809 kg
