Главная Каталог продукции Toolunited 12 302-05 - Stepped countersinking tool / tapered countersinking tool 475 40.000

475 40.000

475 40.000 475 40.000

475 40.000

Gühring
Артикул: 9004750400000
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
DAMPF ANGELASSEN
COMPC Company code
GG - Gühring
CRCLDIN Tool application class
N
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
12 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter 1st step maximum
40 mm
Delivery state valid from
12/1/2021
DIN
MKG00302085
FamilyProducts
HSS KEGELSENKER 90 40,000 DIN 335RN MKFO
FHH Flute helix hand
R - Hand of helix right
GEP Guide element property
0 - Without guide elements
GPP Guide pilot
0 - Without pilot
GRDMFG Grade manufacturers designation
HSS
GRDPRIO Standard designation of the grade main application
HSS
HAND Cutting direction
R - Right
ID Technical product number
9004750400000
Interface codes
J6 /
ISYC Subclass
302-05 - Stepped countersinking tool / tapered countersinking tool
LCF Length chip flute
30 mm
LF Functional length
56 mm
LOC-03 CCFMS Connection code form
20
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
MKG Morse taper
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0030
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
MKG00302085
LPR Protruding length
56 mm
LS Shank length
99 mm
LU Usable length
51 mm
Name Identifying order number
475 40.000
NOF Flute count
11
OAL Overall length
150 mm
PHD Premachined hole diameter
13 mm
SIG Point angle 1st step
90 Degree
STDLET Standard letter to the standard number
B
STDNO Standard
DIN335
TL Taper length
14 mm
Working process
SPR - Profile counterboring
WT Weight of item
0.611 kg
