Главная Каталог продукции Toolunited 12 302-05 - Stepped countersinking tool / tapered countersinking tool 475 100.000

475 100.000

Артикул: 9004751000000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

31.5 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter 1st step maximum

100 mm

Delivery state valid from

12/1/2021

DIN

MKG00402085

FamilyProducts

HSS KEGELSENKER 90 100,000 DIN 335RN MKF

GEP Guide element property

0 - Without guide elements

GPP Guide pilot

0 - Without pilot

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

HAND Cutting direction

R - Right

ID Technical product number

9004751000000

Interface codes

J6 / J61

ISO

MKG20C0040$$$$

ISYC Subclass

302-05 - Stepped countersinking tool / tapered countersinking tool

LCF Length chip flute

55 mm

LF Functional length

94.5 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

MKG Morse taper

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0040

LOC-03 ISO

MKG20C0040$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00402085

LPR Protruding length

94.5 mm

LS Shank length

124 mm

LU Usable length

88 mm

Name Identifying order number

475 100.000

NOF Flute count

OAL Overall length

212 mm

PHD Premachined hole diameter

32 mm

SIG Point angle 1st step

90 Degree

STDLET Standard letter to the standard number

STDNO Standard

DIN335

TL Taper length

34.25 mm

Working process

SPR - Profile counterboring

WT Weight of item

3.498 kg
