Главная Каталог продукции Toolunited 12 302-04 - Counterbore 325 10.000

325 10.000

Артикул: 9003250100000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

TIN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

10 mm

DCONMSLD Shank diameter lower limit

-0.036 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00800105

FamilyProducts

HSS S-FLACHSENKER 10,000 DIN 373RN MITT

FHA Flute helix angle

29 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

56 mm

GEP Guide element property

0 - Without guide elements

GPD Guide pilot diameter

5.5 mm

GPL Guide pilot length

6.3 mm

GPP Guide pilot

1 - With fixed pilot

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

HAND Cutting direction

R - Right

ID Technical product number

9003250100000

Interface codes

J6 / J61

ISO

ZYL01F8000$$$$

ISYC Subclass

302-04 - Counterbore

LCF Length chip flute

35 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 ISO

ZYL01F8000$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

LPR Protruding length

45 mm

LS Shank length

35.5 mm

Name Identifying order number

325 10.000

NOF Flute count

OAL Overall length

80 mm

SIG Point angle 1st step

180 Degree

STDNO Standard

DIN373

THSZMS Connection thread nominal size machine side

M 5

Working process

SPL - Spot facing

WT Weight of item

0.027 kg
