Главная Каталог продукции Toolunited 12 302-00 - Drill unspecified 5687 1.000

5687 1.000

Артикул: 9056870010000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

4 - With Coolant entry, axial on hole circle

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter minimum

1 mm

DCONMSLD Shank diameter lower limit

-0.006 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00300115

FamilyProducts

VHM TLB EB100 75XD R UG MMS

FHH Flute helix hand

N - Hand of helix neutral

GRD2ND Standard designation of the grade 2nd application

VHM

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

HF-K

HAND Cutting direction

R - Right

ID Technical product number

9056870010000

Interface codes

J6 /

ISYC Subclass

302-00 - Drill unspecified

LCF Length chip flute

82 mm

LF Functional length

114.7 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0030

LOC-03 DCONMS Diameter

3 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00300115

LPR Protruding length

88 mm

LS Shank length

28 mm

LU Usable length

80 mm

Name Identifying order number

5687 1.000

NOF Flute count

OAL Overall length

115 mm

PL Point length

0.3 mm

SIG Point angle 1st step

100 Degree

STDNO Standard

WN 42

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.011 kg
