Главная Каталог продукции Toolunited 12 302-00 - Drill unspecified 5022 7.000

5022 7.000

Артикул: 9050220070000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

B - Steel body with brazed carbide inserts

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating

TIN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter minimum

7 mm

DCONMSLD Shank diameter lower limit

-0.011 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL01600115

FamilyProducts

VHM-KOPF S-TIEFLOCHBOHRER 40XD 7,0 ZL HA

FHH Flute helix hand

N - Hand of helix neutral

GRD2ND Standard designation of the grade 2nd application

HM-BEST,

GRDMFG Grade manufacturers designation

HMKOPF

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Technical product number

9050220070000

Interface codes

J6 /

ISYC Subclass

302-00 - Drill unspecified

LCF Length chip flute

322 mm

LF Functional length

368.9 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600115

LPR Protruding length

322 mm

LS Shank length

48 mm

LU Usable length

308 mm

Name Identifying order number

5022 7.000

NOF Flute count

OAL Overall length

370 mm

PL Point length

1.1 mm

SIG Point angle 1st step

120 Degree

STDNO Standard

WN TLB

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.147 kg
