5018 5.000
5018 5.000
Артикул:
9050180050000
В наличии
Характеристики
BMC Body material code
B - Steel body with brazed carbide inserts
CCONMS Connection count machine side
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating
TIN
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
4 - With Coolant exit, axial on hole circle
DC Cutting diameter minimum
5 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01600115
FamilyProducts
VHM-KOPF S-EINLIPPEN-TLB EB80 20XD ZL HA
FHH Flute helix hand
N - Hand of helix neutral
GRD2ND Standard designation of the grade 2nd application
HM-BEST,
GRDMFG Grade manufacturers designation
HMKOPF
GRDPRIO Standard designation of the grade main application
HW
HAND Cutting direction
R - Right
ID Technical product number
9050180050000
Interface codes
J6 /
ISYC Subclass
302-00 - Drill unspecified
LCF Length chip flute
130 mm
LF Functional length
179.2 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01600115
LPR Protruding length
132 mm
LS Shank length
48 mm
LU Usable length
120 mm
Name Identifying order number
5018 5.000
NOF Flute count
1
OAL Overall length
180 mm
PL Point length
0.8 mm
SIG Point angle 1st step
120 Degree
STDNO Standard
WN TLB
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
BVB - Drilling
WT Weight of item
0.093 kg
