23940180
23940180
Артикул:
23940180
В наличии
Характеристики
BD Body diameter
45 mm
COATN Coating
ohne
COMPC Company code
CE - Ceratizit
Delivery state valid from
10/1/2021
DIN
SEH04500105
FamilyProducts
HSS SCHNEIDEISEN
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-05 - Thread cutting die, round shape
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SEH die stock connection
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0450
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SEH04500105
Name Identifying order number
23940180
NOF Flute count
5
OAL Overall length
14 mm
TCTR Thread tolerance class
ISO 6g
THFT Thread form type
MF
TP Thread pitch
1 mm
Working process
No working processes available
