4011503630
4011503630
Артикул:
4011503630
В наличии
Характеристики
COATN Coating
ohne
COMPC Company code
CE - Ceratizit
DIN
ZYL00400105
FamilyProducts
HSSE 1/100 MASCHINENREIBAHLE LINKSDRALL
FHH Flute helix hand
R - Hand of helix right
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
311-01 - Solid cylindrical reamer
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00400105
LPR Protruding length
44 mm
LS Shank length
28 mm
LU Usable length
39 mm
Name Identifying order number
4011503630
OAL Overall length
70 mm
Working process
No working processes available
