Главная Каталог продукции Toolunited 11 401-00 - Adaptive item converter, extender, reducer unspecified S025LQSA-10

S025LQSA-10

Артикул: 6321765

В наличии

В корзину

Описание

Характеристики

CCSWS Connection code style

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

1 - With data chip

Delivery state valid from

10/15/2023

DF Flange diameter

15 mm

DIN

ZYL02500115

FamilyProducts

Cylindrical steel shank

HAND Cutting direction

N - Neutral

ID Technical product number

6321765

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LB Body length 1

10 mm

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

IL-K-1399

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

IL-TT35 MS15

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

25 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02500115

LPR Protruding length

100 mm

Name Identifying order number

S025LQSA-10

OAL Overall length

104.9 mm

WT Weight of item

0.35 kg
