Главная Каталог продукции Toolunited 11 401-04 - Reducer, primary design 77.200.08

77.200.08

Артикул: 4557366

В наличии

В корзину

Описание

Характеристики

BD Body diameter

20 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

0 - Without coolant exit

CZCWS Connection size code

0080

DCONWS Diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

11 mm

DIN

ZYL02000115

FamilyProducts

Extension for shrink fit chuck 77... extra slim type

HAND Cutting direction

N - Neutral

ID Technical product number

4557366

Interface codes

J6 /

ISYC Subclass

401-04 - Reducer, primary design

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0080

LOC-01 DCONWS Diameter

8 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL00800105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000115

LPR Protruding length

200 mm

Name Identifying order number

77.200.08
