50818038
50818038
Артикул:
50818038
В наличии
Характеристики
APMX Depth of cut maximum
34 mm
COATN Coating
TiAlN
COMPC Company code
CE - Ceratizit
DCX Cutting diameter maximum
13 mm
Delivery state valid from
10/1/2021
FamilyProducts
VHM SCHAFTGEWINDEFRÄSER M. SENKFASE
FHH Flute helix hand
R - Hand of helix right
Interface codes
/
ISYC Subclass
303-09 - Thread end mill
LOC-03 DCONMS Diameter
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LS Shank length
48 mm
MILTTY Mill tool type ISO
T - Thread cutter
Name Identifying order number
50818038
OAL Overall length
100 mm
THFT Thread form type
G
TP Thread pitch
1.337 mm
TPI Threads per inch
19 1/in
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
4
