5080714500

Артикул: 5080714500

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

28.7 mm

COATN Coating

AlCrN

COMPC Company code

CE - Ceratizit

DCX Cutting diameter maximum

10.92 mm

Delivery state valid from

10/1/2021

FamilyProducts

HPC VHM SCHAFTGEWINDEFRÄSER M. SENKFASE

FHH Flute helix hand

R - Hand of helix right

Interface codes

ISYC Subclass

303-09 - Thread end mill

LF Functional length

30.6 mm

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LS Shank length

48 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

5080714500

OAL Overall length

102 mm

THFT Thread form type

TP Thread pitch

1.5 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
