Главная Каталог продукции Toolunited 11 303-00 - End mill unspecified 52756040

52756040

Артикул: 52756040

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

4 mm

COATN Coating / Покрытие

APB72S

COMPC Company code

CE - Ceratizit

DC Cutting diameter

4 mm

Delivery state valid from

10/1/2021

DIN

ZYL00600105

DN Neck diameter

4 mm

FamilyProducts

VHM FRÄSER 3D FINISH

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

LH Head length

18 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

LPR Protruding length

26 mm

LS Shank length

36 mm

Name Identifying order number

52756040

OAL Overall length

62 mm

PRFRAD2 Profile radius 2

6 mm

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
