Главная Каталог продукции Toolunited 11 303-00 - End mill unspecified 52755101

52755101

Артикул: 52755101

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

6 mm

COATN Coating

APB72S

COMPC Company code

CE - Ceratizit

DC Cutting diameter

10 mm

Delivery state valid from

10/1/2021

DIN

ZYL01000105

FamilyProducts

VHM FRÄSER 3D FINISH

FHH Flute helix hand

R - Hand of helix right

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LPR Protruding length

40 mm

LS Shank length

40 mm

Name Identifying order number

52755101

OAL Overall length

80 mm

PRFA Profile included angle

140 Degree

PRFRAD2 Profile radius 2

200 mm

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
